Absolute Arm Compact

The Absolute Arm Compact, the most accurate and portable measuring arm, for touch probe measurement to ultra-high accuracy. Easy-to-use, reliable, IP54-rated.
A wide range of easily interchangeable, compatible devices.

Let’s start project together!

Tell us about your project and we’ll get back to you within 24 hours.

    What is your name?*

    What company do you represent?

    Phone number?*

    A few words about your project*

    Product features

    Measurement volume

    1.2 m

    ISO 10360-12

    certification as standard

    2 accuracy levels

    83 and 85 series

    24-month warranty

    on all Absolute Arm systems

    Volume extension

    Leap Frog Kit or GridLOK system allows large-volume measurement

    Quick Measure

    allows basic measurements without additional software

    HP-L-8.9 Laser Scanner

    (as option) turns the Absolute Arm Compact into a scanning solution

    Service centres

    means quality service and support is always nearby

    Real-time remote monitoring

    Compatibility with Metrology Asset Manager, the leading solution for of Industry 4.0 asset performance management

    Full protection

    the world's first IP54-rated portable measuring arm for complete protection and confidence in challenging environments

    Verification artefacts

    supplied with each arm,
    allow users to verify system performance according to certification

    SMART

    Self-Monitoring Analysis and Reporting Technology (SMART) that manages the arm in the field by monitoring diagnostics

    Technical Specifications

    Criteria for choosing Absolute Arm CompactHexagon
    AccuracyAvailability of different accuracy/metrology levels?Yes (2 levels)
    Certification for volumetric accuracy of probing, according to ISO 10360-12 (certificate included)?Yes (standard)
    Certification for volumetric accuracy of probing, according to ISO 10360-2 (certificate included)?Yes (optional)
    Does the system include artefacts and software so you can verify its accuracy performance
    compared to the specifications (software scripts/guides)?
    Yes
    Does the system have environment monitoring sensors (vibration, displacement, tilt,
    inclination, jointstress, ambient temperature) alerting the operator in any shop-floor environment
    (with audio, visual and haptic warnings), to ensure proper handling and prevent loss of accuracy?
    Yes
    Availability of extended-volume measurement options
    (i.e. up to 5-10 times the system’s standard volumetric range)?
    Yes (Leapfrog/GridLOK)
    Robustness
    Does the system have IP54-rating for protection when measuring in harsh environments?Yes
    Does the system have IP54-status monitoring sensors to provide warnings when compromised?Yes
    Can the arm measure repeatably in an environmental temperature up to 45°C?Yes (5-45°C)
    Is the system thermally stable (i.e. high-end carbon-fibre construction)?Yes
    Compliance with impact, shock vibration, emissions and environmental norms (CE, IEC, etc.)?Yes (full list in manual)
    Does the system include high-quality cables with safe push-pull locking mechanism?Yes
    Does the system include software for diagnostics and performance monitoring?Yes (S.M.A.R.T.)
    Is a 24-month warranty offered as standard with all systems?Yes
    Ease of use
    Can the system measure immediately after power-on (no warm-up time)?Yes
    Does the system feature Absolute Encoders
    (with no need to be initialised before measurement)?
    Yes
    Can you easily swap probes and scanners without extra tools?Yes
    Can probes or scanners be mounted and used without stopping to calibrate or select
    the probe in the software?
    Yes
    Does the arm allow infinite rotation on major axes?Yes
    Does the system come with a single carrying case with wheels for mobility?Yes
    Does the system’s counterbalance mechanism allow the arm to be used comfortably
    and with a single hand (with an ergonomically designed wrist)?
    Yes
    Is battery operation available (with hot-swappable batteries)?Yes (Control Pack W or B)
    Is wireless measurement available?Yes (Control Pack W)
    Is there a variety of mounting options (magnetic, tripod, vacuum base)?Yes
    Are other probe types (extended, angled, curved or tube-measurement probes) available,
    in case you need to add more measurement capabilities later?
    Yes
    Can the system connect to an asset management platform providing real-time remote
    performance monitoring and location tracking through a user-friendly dashboard?
    Yes
    Can the system accept the mounting of an external laser scanner?Yes (HP-L-8.9)
    Can the operator use the arm as a mouse (for remote computer control)?Yes
