| Point distance | 0.1 ~ 3 mm |
| Light source | Infrared VCSEL structured light |
| Optimal working distance | 400 mm |
| Depth of field | 160 - 1400 mm |
| Max. FOV | 434 x 379 mm (under optimal work distance) |
| Scan speed | 980,000 points/s, up to 14 FPS |
| Align modes | Feature Alignment, Hybrid Alignment, Texture Alignment, Global Markers |
| Safety | Eye-safe |
| Texture scan | Yes |
| Outdoor scanning | Yes |
| Interface | USB2.0 or above |
| Output formats | OBJ; STL; PLY; P3; 3MF |
| Scanner size | 220 x 46 x 55 mm |
| Carrying case size | 245 x 245 x 90 mm |
| Scanner body weight | 500g |
| Operating temperature range | 0 - 40℃ |
| Operating humidity range | 10 - 90% |
| Certifications | CE, FCC, ROHS, WEEE, KC |
| Recommended
configuration | OS: Win10/11, 64 bit; Graphics card: NVIDIA GTX1060;
Video memory: ≥6GB; Processor: I7-11800H; Memory: ≥32GB |
| Basic computer
configuration | OS: Win10, 64 bit; Graphics card: NVIDIA GTX1050;
Video memory: ≥4GB; Processor: I7-7700H; Memory: ≥16GB |
